MILEMAX(RX501)
Product Details
Reinforced Tire for Truck
1、All - weather steel sheet of the whole tread ensures heat dissipation of pattern block under different environments and improves starting acceleration.
2、Specially treated steel sheet on the special shoulder pattern block effectively reduces resonance.
3、Four longitudinal drainage ditches provide guarantee for tire's wetland drainage performance.
4、Special tread formula realizes firmness and durability, which ensures tire rigidity and enhances tire wearability.
Product data
| SIZE | LOAD INDEX | SPEED RANGE | PLY | STANDARD RIM | SECTION WIDTH (MM) | OVERALL DIAMETER (MM) | MAX LAOD SINGLE | MAX LOAD DOUBLE | MAX PRESSURE | TREAD DEPTH (MM) | |||
| KG | LBS | KG | LBS | KPa | PSI | ||||||||
| 155R13C | 85/83 | N | 6PR | 4.50B | 157 | 578 | 515 | 1135 | 487 | 1074 | 350 | 51 | 8.0 |
| 155R13C | 90/88 | N | 8PR | 4.50B | 157 | 578 | 600 | 1323 | 565 | 1245 | 450 | 65 | 8.0 |
| 165R13C | 91/89 | N | 6PR | 4 1/2J | 165 | 594 | 615 | 1356 | 580 | 1269 | 375 | 54 | 8.0 |
| 165R13C | 94/93 | N | 8PR | 4 1/2J | 165 | 594 | 670 | 1475 | 650 | 1435 | 450 | 65 | 8.0 |
| 165/70R13LT(C) | 88/86 | T | 6PR | 5J | 170 | 562 | 560 | 1235 | 530 | 1170 | 375 | 54 | 8.0 |
| 175R13C | 94/92 | N | 6PR | 5.00B | 177 | 610 | 670 | 1477 | 630 | 1389 | 375 | 54 | 8.0 |
| 175R13C | 97/95 | Q | 8PR | 5.00B | 177 | 610 | 730 | 1609 | 690 | 1521 | 450 | 65 | 8.0 |
| 165/70R14LT | 89/87 | R | 6PR | 5J | 170 | 588 | 580 | 1280 | 545 | 1200 | 375 | 54 | 8.0 |
